Basic Info.
Model NO.
KLWQD-50
Application
Environmental Protection
Type
Turbine Flow Meter
Measuring Media
Gas
Measuring Principle
Electrical Principles
Measurement Object
Closed Pipeline
Certification
CE, ISO, SGS, Ts
Output Type
RS485 or 4~20mA, Pulse
Connection Type
Flanged
Power Supply
Battery, 24VDC
Medium
Natural Gas, Coal Gas
Transport Package
Wooden Box Package
Trademark
kunkeandao
Origin
Weihai
HS Code
9026100000
Production Capacity
3000 Pieces/Year
Product Description
KLWQD series gas turbine flowmeter has the advantages of high measuring precision, good repeatability,
wide measuring range, light structure, simple installation, convenient maintenance, small pressure loss, long
service life and convenient operation.In addition, considering the compressibility of the gas, volume volume,
medium temperature and pressure change, the operating flow rate is directly converted into the standard flow rate
to ensure the accuracy of measure ment.
Product Features
wide measuring range, light structure, simple installation, convenient maintenance, small pressure loss, long
service life and convenient operation.In addition, considering the compressibility of the gas, volume volume,
medium temperature and pressure change, the operating flow rate is directly converted into the standard flow rate
to ensure the accuracy of measure ment.
Product Features
Product parameters
| Model | Flow specification | Starting flow (m3/h) | Flow range (m3/h) | Maximum pressure loss (Kpa) | Nominal pressure (MPa) | Shell material | Accuracy |
| KLWQD-50(D) | G40 | ≤1.3 | 6.5~65 | 0.6 | 1.6 2.5 | Aluminum alloy | 1.0 1.5 |
| G65 | ≤1.6 | 8~100 | 0.9 | ||||
| G100 | ≤2.4 | 10~160 | 2.0 | ||||
| KLWQD-80(D) | G100 | ≤2.4 | 8~160 | 0.7 | |||
| G160 | ≤3.0 | 13~250 | 1.2 | ||||
| G250 | ≤5.0 | 20~400 | 2.2 | ||||
| KLWQD-100(D) | G160 | ≤3.3 | 13~250 | 0.8 | |||
| G250 | ≤4.2 | 20~400 | 1.0 | ||||
| G400 | ≤6.7 | 32~650 | 2.5 | ||||
| KLWQD-150(D) | G400 | ≤7.8 | 32~650 | 0.7 | |||
| G650 | ≤10.0 | 50~1000 | 1.1 | ||||
| G1000 | ≤12.0 | 80~1600 | 2.3 | ||||
| KLWQD-200(D) | G650 | ≤12.0 | 50~1000 | 0.7 | |||
| G1000 | ≤16.0 | 80~1600 | 1.5 | ||||
| G1600 | ≤20.0 | 50~1000 | 2.4 | ||||
| KLWQD-250(D) | G1000 | ≤20.0 | 80~1600 | 0.8 | |||
| G1600 | ≤22.0 | 130~2500 | 1.3 | ||||
| G2500 | ≤25.0 | 200~4000 | 2.5 | ||||
| KLWQD-300(D) | G1600 | ≤22.0 | 130~2500 | 1.0 | |||
| G2500 | ≤25.0 | 200~4000 | 1.5 | ||||
| G4000 | ≤35.0 | 320~6500 | 2.5 |
