Basic Info.
Model NO.
SF
Portable
Non-portable
Physical Analysis Type
Distilling Layered Method
Chemical Analysis Type
Karl Fischer Method
Operating Mode
Keyboard
Heating Mode
Moderate Heating
Off Mode
Manual
Display Screen
6.5 Inch LED
Display Parameters
Concentration, Saturation, Temperature
Dissolved Oxygen Range
0.000-90 Mg/L (Ppm)
Dissolved Oxygen Resolution
0.01/0.1
Dissolved Oxygen Accuracy
± 0.5%
Dissolved Oxygen Saturation
0.0-200%
Saturation Resolution
0.1%
Saturation Accuracy
± 2.0% Fs
Temperature Measurement Range
(-5~130) ºC
Temperature Resolution
0.1 ºC
Relative Temperature Accuracy
± 0.1 ºC
Temperature Compensation
(0~45) ºC
Salinity Compensation
(0.0~50.0) G/L
Air Pressure Compensation Range
(80~105) Kpa
Barometric Resolution
1
Transport Package
Individually Packaged
Specification
160 x 190 x 70mm
Trademark
English Neutral
Origin
China
Production Capacity
50000pieces/Months
Product Description
Instrument features:
1.Adopting a 6.5 inch LED screen, with complete and intuitive parameter display, user-friendly interface operation design, convenient for users to operate and use.
2.Adopting Omron long-life light touch button type, convenient and durable, up to 100000 times or more.
3.Meet the GLP requirements of international standards, with intelligent functions such as automatic calibration, automatic temperature compensation, data storage, USB output, clock display, wireless printing, function settings, and self diagnostic information.
4.The built-in large capacity storage can store 1000 sets of measurement data, which can be transferred through USB flash drive storage. The stored data can be opened using the general office software EXELL, greatly facilitating customer editing.
5.The dissolved oxygen measurement mode has functions of automatic temperature compensation, automatic salinity compensation, and automatic air pressure compensation.
6.The instrument comes standard with a Bluetooth module, which supports wireless Bluetooth printing and is convenient for users to operate. Optional support for wireless Bluetooth data transmission.
7.The new structure of polarographic dissolved oxygen electrode can simultaneously measure temperature, salinity, and dissolved oxygen. Equipped with a dedicated dissolved oxygen electrode calibration kit, electrode polarization only takes 3-5 minutes.
8.When using a combination diaphragm cap to replace a sensitive membrane, simply screw the new diaphragm cap onto the electrode, making it extremely convenient to use.
9.The instrument comes standard with a Bluetooth module, which supports wireless Bluetooth printing and is convenient for users to operate. Optional support for wireless Bluetooth data transmission to mobile computers.
10.Designed to meet the IP54 dust and splash protection level.
