Basic Info.
Model NO.
AGA1010
Gas Sensor
Imported Sensor From Europe
Detection Principle
Paramagnetic
Gases Detected
O2 Oxygen
Measure Range
0-5%Vol, 0-25%Vol, 0-30%Vol
Pretreatment System
Optional
Output Signal
4-20mA / RS485
Zero Drift
±1%F.S/7D
Environment Temperature
-10ºC-50ºC
Reaction Time
≤ 20s ( T90 )
Measure Range Drift
±1%F.S/7D
Transport Package
Carton
Specification
650*500*265mm
Trademark
AIYI
Origin
Nanjing, China
HS Code
8531100000
Production Capacity
10000/Month
Product Description
Detection of the leakage of flammable and toxic gasses used in petroleum and chemical engineering. The Paramagnetic oxygen O2 gas analysis device with Germany sensor is fixed in areas such as workshops, warehouses and storage tanks for real-time monitoring of the concentration of flammable and toxic gasses.
