Basic Info.
Model NO.
AR8100
Customized
Customized
Portable
Portable
Certification
CE
Gas
O2
Type
Oxygen Gas Analyzer
Measuring Range
0~25%
Resolution
0.1%
Response Time
<50 Sec
Operating Temperature
-20~50°c
Operating Humidity
0-95%Rh(Non Gel)
Power
3.7V Li-Battery
Transport Package
Box
Specification
plastic
Trademark
hedao
Origin
China
Production Capacity
100000/Year
Product Description
| Specification: Measuring range: 0~25% The principle of sensor:Electrochemical principle, life for two year Resolution:0.1% Response time:<50 sec Recovery time:<50 sec To alarm:Acoustic,optical double alarm, can set thealarm value,an alarm sound is divided into 80dB Operating temperature:-20~50°C Operating humidity:0-95%RH(Non Gel) Temperature measuring:√ Power Supply: Rechargeable lithium-ion battery, 3.7 Volts (include) |
SMART SENSOR gas detector is a device that detects the presence of gases in an area, often as part of a safety system. This type of equipment is used to detect a gas leak and interface with a control system so a process can be automatically shut down. A gas detector can sound an alarm to operators in the area where the leak is occurring, giving them the opportunity to leave. This type of device is important because there are many gases that can be harmful to organic life.
Gas detectors can be used to detect combustible, flammable and toxic gases, and oxygen depletion, etc. This type of device is widely used in industry and can be found in locations, such as on oil rigs, to monitor manufacture processes and emerging technologies such as photovoltaic. They may also be used in firefighting.
While many of the standard gas detector units were originally fabricated to detect one gas, modern multifunctional or multi-gas devices are capable of detecting several gases at once. Some detectors may be utilized as individual units to monitor small workspace areas, or units can be combined or linked together to create a protection system.
Gas detectors can be used to detect combustible, flammable and toxic gases, and oxygen depletion, etc. This type of device is widely used in industry and can be found in locations, such as on oil rigs, to monitor manufacture processes and emerging technologies such as photovoltaic. They may also be used in firefighting.
While many of the standard gas detector units were originally fabricated to detect one gas, modern multifunctional or multi-gas devices are capable of detecting several gases at once. Some detectors may be utilized as individual units to monitor small workspace areas, or units can be combined or linked together to create a protection system.
