Industrial Online Digital Dissolved Oxygen Meters

Factory direct industrial online digital dissolved oxygen meters. Accurate and reliable measurements for various applications. Find your solution here.
Request a Quote


Basic Info.

Model NO.
+/- 0,1mg/L
Response Time
90% of The Value in Less Than 60 Seconds
Temperature Compensation
Via Ntc
Diameter : 25 mm ; Length : 146 mm
Transport Package
Diameter: 25 mm; length: 146 mm
Production Capacity

Product Description

Industrial Online Digital Dissolved Oxygen Meters
1. The Optical Dissolved Oxygen technology is based on luminescent optical technology. The Optical Dissolved Oxygen sensor is approved by the ASTM International Method D888-05.
2. Without calibration requirements and thanks to an ultra low power technology, the Optical Dissolved Oxygen sensor meets the demands of field works and short or long term campaigns.
3. Without oxygen consumption, this technology allows you an accurate measure in all situation and especially in very low oxygen concentrations

Applications :
Urban wastewater treatment Industrial effluent treatment
Surface water monitoring,
Sea water monitoring, fish farming, aquarium
Drinking water
Measure principle Optical measure by luminescence
Measure ranges 0,00 to 20,00 mg/L
0,00 to 20,00 ppm
Resolution 0,01
Accuracy +/- 0,1mg/L
+/- 0,1 ppm
+/- 1 %
Response time 90% of the value in less than 60 seconds
Frequency of recommended measure >5 s
Water move No necessary move
Temperature compensation Via NTC
Stocking temperature - 10°C to + 60°C
Signal interface Modbus RS-485 (standard) and SDI-12 (option)
Sensor power-supply 5 to 12 volts
Consumption Standby 25 µA
Average RS485 (1 measure/ seconde) : 4,4 mA
Average SDI12 (1 measure/ seconde) : 7,3 mA
Current pulse : 100 mA
Dimensions Diameter : 25 mm ; length : 146 mm
Weight Stainless steel version 450g (sensor + cable 3 m)
Titanium version 300 g (sensor + cable 3 m)
Material Stainless steel 316L, New : body in Titanium
Maximum pressure 5 bars
Connection 9 armoured connectors, polyurethane jacket, bare
wires or waterproof Fisher connector
Protection IP68

Industrial Online Digital Dissolved Oxygen Meters
Industrial Online Digital Dissolved Oxygen Meters
Cable length up to 15m Cable lenght 15 to 100 meters
1- Red Power supply V+ Red Purple Yellow Orange pink Power supply V+
2 - Blue SDI-12 2 - Blue SDI-12
3 - Black Power supply V- 3 - Black Power supply V-
4 - Green B " RS-485 " 4 - Green B " RS-485 "
5 - White A " RS-485 " 5 - White A " RS-485 "
6 - Green/yellow Cable shield 6 - Green/yellow Cable shield

Packing & Delivery:

Electromagnetic flow meter is packed in cartons ,and wooden boxes (from DN80)

Lead time : Most products within 7 working days(if have stock, could be sent same day), customized product would be longer

Delivery process:

1.Use customer's own delivery account, or we help to choose a suitable one
(Usually use FedEx, Ups, DHL, TNT, EMS,etc)

2.Delivery time is 2-7 working days, some products have stock in Malaysia.

3.Help to do the destination customs clearance

Overseas Service Center Address:

Singapore/ Philippines/ Malaysia/ Kroea/ Indonesia/ Germany/ India

Industrial Online Digital Dissolved Oxygen Meters

Industrial Online Digital Dissolved Oxygen Meters
Industrial Online Digital Dissolved Oxygen Meters
Industrial Online Digital Dissolved Oxygen Meters

Q: How long will you give me the reply?
A: we will contact you in 3 hours as soon as we can.

Q:Could I visit your factory?
A: Sincerely invite you to visit our factory,Our factory and office are all in Hangzhou,Zhejiang.

Q: Do you provide samples ?
A: Yes,we have materials in stock to help you to get the samples as soon as we can.

Q: How about the quality of the managements ?
A: We have a complete quality control system , all of our products will be fully pre-inspection by QC departments before shipping to you . We have the certification of ISO,CE we could send the certification test of our company to you.

Q: What is your terms of payment ?
A: We could accept T/T, Paypal, WU ,Credit Assurance

Q: What is the warranty for your product ?
A: Warranty: 2 years, Lifetime maintenance.

Q: How soon can you arrange the production?
A: Once getting your product confirmation and receiving your payment, we will arrange the production immediately. For some products we have it in stock.

Q: Could you provide me the shortest lead time?
A: For somre standard products we have it in stock . Pls tell me your detailed requirements, we will send to you as early as we can.
