Basic Info.
Model NO.
M500T
Portable
Portable
Appliance
Biochemistry, Water Quality Analysis
Certification
ISO9001, CE
Model Number
M500t
pH Range
-2.000 to 20.000 pH
pH Accuracy
±0.002
Mv/ORP Range
-2000.00 to 2000.00 Mv
Conductivity Range
0.000 μs/Cm to 2000 Ms/Cm
Resistivity Range
5.00 Ω Cm~100.0 MΩ Cm
TDS Range
0.000~1000 Ppt
Salinity Range
0.0~80.0 Ppt
Dissolved Oxygen Range
0.00 to 99.99 Ppm
Temperature Range
-10 to 135 ºC, 14 to 275 ºF
Transport Package
Package for Exporting
Specification
37X35X33 cm
Trademark
SKZ
Origin
China
Production Capacity
50000PCS/Year
Packaging & Delivery
Package Size
37.00cm * 35.00cm * 33.00cm
Package Gross Weight
5.500kg
Lead Time
15 days (1 - 1 Pieces)
20 days (2 - 5 Pieces)
To be negotiated ( > 5 Pieces)
20 days (2 - 5 Pieces)
To be negotiated ( > 5 Pieces)
Product Description
M500T Benchtop Multi Parameter Aquaculture Water Quality Analyzer pH ORP TDS Dissolved Oxygen Turbidity Meter
GENERAL FEATURES 1. Color High contrast LCD touchscreen, 7.0 inches. 2. Intelligent operation system provides features including user management, calibration management, method management, data management and etc. 3. Multi-reading feature allows auto-read, timed-read and continuous-read. 4. Automatic/Manual temperature compensation ensures accurate results. 5. Data Storage 1000 sets for each parameter (GLP-compliant). 6. Data analysis feature helps user review, compare and recalculate results. 7. Support for USB or RS-232 communication. 8. Reset feature automatically resumes all settings back to factory default options. 9. IP54 waterproof. pH 1. 1-6 points calibration with Standard Recognition. 2. Selectable pH buffer groups, including DIN, NIST, USA, MERK, JIS, GB. 3. Support for pH standard group customization. 4. Automatic electrode diagnosis with pH slope and offset display. Ion 1. 1-6 points calibration 2. Selectable measurement unit, including μg/L, mg/L, g/L, mmol/L, pX, ppm, ppb, etc. 3. Multi-measurement modes are supported, including Direct Reading mode, Standard Addition mode, Sample Addition mode and GRAN mode. 4. Over 10 methods are built-in, including F-, Cl-, Br-, I-, NO3-, BF4-, NH4+, K+, Na+, Ca2+, Cu2+, Pb2+, Ag+ and etc., user-defined method is supported. Conductivity 1. 1-5 points calibration with Standard Recognition. 2. Settable parameters, including cell constant, reference temperature (5/10/15/18/20/25°C), temperature compensation coefficient and TDS factor. 3. Temperature compensation type (none, linear, pure water). DO 1. Support for air-saturated water or zero oxygen calibration. 2. Auto barometric pressure compensation. 3. Manual Salinity Factor Correction. 4. Selectable pressure unit, including kPa, mbar, Torr, Atm. Includes 1. E-301-QC 3 in 1 pH composite electrode 2. DJS-1VTC EC electrode 3. DO-958-Q polarographic DO electrode 4. NIST pH standard solution(4.01, 7.00, 10.01) , 50ml/vial (1413μS/cm EC standard solution, 50ml, 1 vial) 5. REX-6 electrode stand 6. Touch pen
Specification
| Model | M500T | |
| Parameters | pH/EC/ISE/DO/Temp. (mV/ORP/pX/Resistivity/TDS/Sal./DO Saturation) | |
| pH | Range | -2.000 to 20.000 pH |
| Resolution | 0.1, 0.01, 0.001pH | |
| Accuracy | ±0.002 pH | |
| Calibration Points | Up to 6 | |
| Standard Customization | Yes | |
| Calibration Reminder | Yes | |
| Standard Recognition | NIST, GB, DIN, USA, MERK, JIS buffers | |
| Slope Limit | Yes | |
| mV/ORP | Range | -2000.00 to 2000.00 mV |
| Resolution | 0.1, 0.01 mV | |
| Accuracy | ±0.1 mV or ±0.03% of reading whichever is greater | |
| EH ORP Mode | Yes | |
| ORP Calibration Points | 1 custom point (relative mV) | |
| pX | Range | -2.000 to 20.000 pX |
| Resolution | 0.1, 0.01, 0.001 pX | |
| Accuracy | ±0.002 pX | |
| Calibration Points | Up to 6 | |
| ISE | Range | 1.000e-9 to 9.999e+9 |
| Units | mol/L, mmol/L, g/L, mg/L, μg/L, ppm, ppb | |
| Resolution | Up to 4 significant digits | |
| Accuracy | ±0.3% | |
| Calibration Points | Up to 6 | |
| Conductivity | Range | 0.000 μS/cm to 2000 mS/cm |
| Resolution | 0.001 μS/cm minimum, various with range selection | |
| Accuracy | ±0.5% FS | |
| Reference Temperature | 5, 10, 15, 18, 20, 25 ºC | |
| Calibration Points | Up to 5 | |
| Calibration Reminder | Yes | |
| Standard Recognition | 10 μS/cm, 84 μS/cm, 500 μS/cm, 1413 μS/cm, 12.88 mS/cm; 146.5μS/cm, 1408μS/cm, 12.85mS/cm, 111.3mS/cm | |
| Resistivity | Range | 5.00 Ω·cm~100.0 MΩ·cm |
| Resolution | 0.01 Ω·cm minimum | |
| Accuracy | ±0.5% FS | |
| TDS | Range | 0.000~1000 ppt |
| Resolution | 0.001 ppm minimum, changed with range | |
| Accuracy | ±0.5% FS | |
| Salinity | Type | NaCl |
| Range | 0.0~80.0 ppt | |
| Resolution | 0.1ppt | |
| Accuracy | ±1ppt | |
| Dissolved Oxygen Concentration - Polarographic | Range | 0.00 to 99.99 ppm |
| Resolution | 0.01 ppm | |
| Accuracy | ±0.10ppm,(0.00~50.00)ppm ±0.50ppm,(50.0~99.99)ppm | |
| Calibration Reminder | Yes | |
| Calibration Points | Air-saturated water or zero point | |
| Barometric Compensation | Yes | |
| Manual Salinity Factor Correction | Yes | |
| % Saturation - Polarographic | Range | (0.0 to 600)% |
| Resolution | 0.10% | |
| Accuracy | ±2.0% | |
| Temperature | Range | -10 to 135 ºC, 14 to 275 ºF |
| Unit | ºC, ºF | |
| Resolution | 0.1 | |
| Accuracy | ±0.1ºC | |
| Measurement | Reading Mode | Auto Read (Fast, Medium, Slow), Timed, Continuous |
| Reading Prompts | Reading, Stable, Locked | |
| Temp. Compensation | ATC, MTC | |
| Data management | Data Storage | 1000 Groups |
| GLP Features | Yes | |
| Log Management | Yes | |
| Inputs | pH Electrode | BNC(Q9) |
| DO with Temp. Probe | 4-pin aviation connector | |
| Conductivity with Temp. Probe | 5-pin aviation connector | |
| Outputs | USB | USB 2.0 flash memory device, PC, scanner, |
| RS 232 | printer, auto-sampler | |
| Display options | Backlight | Yes |
| Auto Shutdown | 1~60 min, off | |
| IP Rating | IP54 | |
| Date and Time | Yes | |
| General | Power | AC Adapter, 100-240V AC input, DC24V output |
| Dimensions | 220×195×68 mm | |
| Weight | 950g (2.09 lb) | |
| Dimensions (Carton) | 370×305×330 mm | |
| Weight (Gross) | 5.5 kg | |
