Basic Info.
Model NO.
FS-N18N
Thread Type
M
Wiring Type
Three-Wire
Measuring Medium
Gas
IP Rating
IP20
Certification
CE
Customized
Non-Customized
Transport Package
Wooden
Specification
0.5kg
Origin
Germany
HS Code
9026209010
Production Capacity
50000PCS/Year
Product Description
| Model | FS-N11CN | FS-N11MN | FS-N11N | FS-N12N | FS-N13N | FS-N14N | FS-N12CN | |||
| Type | Standard 1 output M8 connector*1 | Monitor output Cable | Standard 1 output Cable | High functionality 2 output Cable | Standard 1 output M8 connector*1 | |||||
| Output | NPN | |||||||||
| Main unit/expansion unit | Main unit | Expansion unit | Main unit | Expansion unit | ||||||
| Control output | 1 NPN open collector 24 V; 1 output max: 100 mA or less; 2 output total: 100 mA or less (used stand-alone)/20 mA or less (multiple connections); residual voltage 1 V or less | 2 NPN open collector 24 V; 1 output max: 100 mA or less; 2 output total: 100 mA or less (used stand-alone)/20 mA or less (multiple connections); residual voltage 1 V or less | 1 NPN open collector 24 V; 1 output max: 100 mA or less; 2 output total: 100 mA or less (used stand-alone)/20 mA or less (multiple connections); residual voltage 1 V or less | |||||||
| Monitor output (1-5 V) | - | 1 | - | |||||||
| External input | 1 Input time 2 ms (ON)/20 ms (OFF) or more (25 ms or more (ON/OFF) when external calibration is selected.) | - | 1 Input time 2 ms (ON)/20 ms (OFF) or more (25 ms or more (ON/OFF) when external calibration is selected.) | |||||||
| Response time | 50 µs (HIGH SPEED) /250 µs (FINE) /500 µs (TURBO) /1 ms (SUPER) /4 ms (ULTRA) /16 ms (MEGA) | |||||||||
| Multiple connections to Expansion units | Up to 16 units can be connected total (two output type is treated as two units) | |||||||||
| Light source LED | Red, 4-element LED | |||||||||
| APC | ON/OFF switchable (Factory setting: OFF) | |||||||||
| Number of interference prevention units | 0 for HIGH SPEED; 4 for FINE; 8 for TURBO/SUPER/ULTRA/MEGA (When set to double, the number of interference-prevention units will be doubled.) | |||||||||
| Rating | Power voltage | 12 to 24 VDC ±10 %, Ripple (P-P) 10 % or less | ||||||||
| Current Consumption | Normal: 900 mW or less (36 mA max. at 24 V, 48 mA max. at 12 V)*2 Eco on mode: 800 mW or less (32 mA max. at 24 V, 39 mA max. at 12 V)*2 Eco Full mode: 470 mW or less (19 mA max. at 24 V, 23 mA max. at 12 V) | |||||||||
| Environmental resistance | Ambient light | Incandescent lamp: 20,000 lux or less, Sunlight: 30,000 lux or less | ||||||||
| Ambient temperature | -20 to +55 °C -4 to +131 °F (No freezing)*3 | |||||||||
| Relative humidity | 35 to 85 % RH (No condensation) | |||||||||
| Vibration resistance | 10 to 55 Hz, Double amplitude 1.5 mm 0.06", 2 hours in each of the X, Y, and Z directions | |||||||||
| Shock resistance | 500 m/s2, 3 times in each of the X, Y, and Z directions | |||||||||
| Case material | Both main unit and expansion unit housing material: Polycarbonate | |||||||||
| Weight | Approx. 22 g | Approx. 75 g | Approx. 45 g | Approx. 80 g | Approx. 70 g | Approx. 22 g | ||||
| *1 Use a cable length of 30 m 98.43' or less for M8 connector and e-CON connector types. *2 Increases 100 mW (4.0 mA) for High Speed mode *3 One or two more units connected: -20 to +55 °C (-4 to +131 °F); 3 to 10 more units connected: -20 to +50 °C (-4 to +122 °F); 11 to 16 more units connected: -20 to +45 °C (-4 to +113 °F). When using 2-outputs, one unit is counted as two units. All temperature regulations are for when the unit is mounted on a DIN rail and installed on metal sheeting. | ||||||||||
