Basic Info.
Model NO.
TQN18-08NO
Standard
Standard
Application
Corridor
Size
86 Type
Certification
CE
Model
Tqn18-08no
Detaction Distance
8mm
Protection Degree
IP67
Output
NPN Normally Open
Circuit Protection
Short-Circuit Protection
Working Voltage
10~30V DC
Transport Package
a Pieces /Box
Specification
2M
Trademark
AkuSense
Origin
Guangdong, China
HS Code
90330000
Production Capacity
60000pieces/Year
Product Description
Product Description
Product Advantages
1: Non-contact position detection, no wear and tear, high reliability
2: High sensitivity, high repeatability, product life up to 8 years
3: A variety of housing materials, from stainless steel, nickel-copper alloy to plastic.
4: Complete specifications, covering almost all sizes.
5: IP67 protection, excellent water and oil resistance.
Product Features
1:6mm (extral small), built-in amplifier
2:8mm sensing distance, the longestsensing distance in the industry
3:Sensing surface on the top and at the frontto suit your needs
Technical specifications
Size structure and Circuit diagram
Factory environment
Part of the process
FAQ
Q : What is the MOQ?
A : 1pcs
Q : Can I customize a special sensor?
A : Sure
Q : Can I get a lower price if I order large quantities?
A : Yes, Cheaper prices with bigger size orders
Q : Can I get a sample?
A : Of course, but you need to pay the minimum sample fee
Q : When will you ship my order?
A : 1 day shipping guarantee for stock item and 3-4 weeks for non-stock items.
Q : How about the quality guarantee period ?
A : Our warranty period is one year since from shipping date.
Q : Can I add or delete items from my order if I change mind?
A : Yes, but you need to tell us asap, if your order has been done in factory production line, we cannot change it.
Q : How can you guarantee the production quality?
A : The quality of products has passed UL&CE&ISO140001&IS09001certification. production plant have 20+ years professional sensor manufacturing history and products have been supplied to many 500 companies and continue to purchase
Product Advantages
1: Non-contact position detection, no wear and tear, high reliability
2: High sensitivity, high repeatability, product life up to 8 years
3: A variety of housing materials, from stainless steel, nickel-copper alloy to plastic.
4: Complete specifications, covering almost all sizes.
5: IP67 protection, excellent water and oil resistance.
Product Features
1:6mm (extral small), built-in amplifier
2:8mm sensing distance, the longestsensing distance in the industry
3:Sensing surface on the top and at the frontto suit your needs
Technical specifications
| Model | TQN18-08NO |
| Connection Method | Cable-type |
| Installation Method | Unflush |
| Size | Q18 |
| Detaction Distance | 8mm±10% |
| Output | NPN normally open |
| Housing Material | Plastic |
| Working Voltage | 10~30V DC |
| Residual Voltage | <1.5V |
| Load Current | 150mA |
| Current Consumption | <10mA |
| Leakage Current | <0.01mA |
| Switch Mode | 300Hz |
| Repeatability | <1.0%(Sr) |
| Hysteresis | <15%(Sr) |
| Sensing Surface Material | ABS |
| Ambient Temperature | -25ºC~+75ºC |
| Circuit Protection | Short-circuit protection |
| Protection Degree | IP67 |
Size structure and Circuit diagram
Factory environment
Part of the process
FAQ
Q : What is the MOQ?
A : 1pcs
Q : Can I customize a special sensor?
A : Sure
Q : Can I get a lower price if I order large quantities?
A : Yes, Cheaper prices with bigger size orders
Q : Can I get a sample?
A : Of course, but you need to pay the minimum sample fee
Q : When will you ship my order?
A : 1 day shipping guarantee for stock item and 3-4 weeks for non-stock items.
Q : How about the quality guarantee period ?
A : Our warranty period is one year since from shipping date.
Q : Can I add or delete items from my order if I change mind?
A : Yes, but you need to tell us asap, if your order has been done in factory production line, we cannot change it.
Q : How can you guarantee the production quality?
A : The quality of products has passed UL&CE&ISO140001&IS09001certification. production plant have 20+ years professional sensor manufacturing history and products have been supplied to many 500 companies and continue to purchase
